UBio-X QScan

UBio-X QScan is an all-in-one smart access control terminal
that integrates QR code and card authentication.

Catalog Download

자산 1QScan

UBio-X QScan

UBio-X QScan is an all-in-one smart access control terminal that integrates QR code and card authentication.

Catalog Download

Support for Various Authentication Methods

It supports not only QR codes but also various 1D/2D barcode formats, such as Data Matrix, PDF417, and Code 39.
It can be flexibly applied to various authentication environments, such as mobile access passes, visitor QR codes, and reservation QR codes.

QR Code

QR Code

Data Matrix

Data Matrix

PDF417

PDF417

Code 39

Code 39

IK09-rated
Damage-Resistant Design

The AC-5000 IK is an IK09-rated
This product features a damage-resistant design.
With its exceptional durability, it can withstand any outdoor environment
It is safe to use.

Flexible System Scalability

It supports various communication interfaces, including TCP/IP, Wiegand In/Out, RS485, and RS232.
It can be integrated with existing access control systems and RF card infrastructure to be applied in a variety of on-site environments.

TCP/IP

Network-Based Communications

Wiegand In/Out

Integration with Existing Controllers

RS485

Support for Connecting Multiple Devices

RS232

Support for Integration with External Devices

IP65-certified
Dustproof and
Waterproof Design

The AC-5000 IK features an IP65-rated dust- and water-resistant design,
With its exceptional durability, it can withstand any external environment
You can install it and start using it.

Support for Contactless Access Control Systems

It supports one-time QR codes, integration with advance reservations, and automatic access control.
It allows for contactless access control by managing the entry of visitors and reservation holders without the need to issue separate cards.

Equipped with anti-counterfeit fingerprint technology

Made of rubber, paper, film, clay, or silicone
Capable of detecting even forged fingerprints
It features high-performance counterfeit fingerprint detection (LFD) technology.

01

Schedule a Visit

Schedule a Visit

Register your visit information and
Schedule an appointment.

›

02

QR Code Issuance

QR Code Issuance

Based on reservation information
We issue a one-time QR code.

›

03

Access Approval

Access Approval

After automatic permission verification
Access is granted.

›

04

Resume Management

Resume Management

Secure Access Logs
Store and manage.

Intuitive User Interface

Equipped with a 2.8-inch color LCD, it visually displays authentication status and user guidance information.
The 3000K white LED and low-power QR module design ensure reliable performance even
in short-range scanning environments.

Equipped with anti-counterfeit fingerprint technology

Made of rubber, paper, film, clay, or silicone
Capable of detecting even forged fingerprints
It features high-performance counterfeit fingerprint detection (LFD) technology.

01
Wide Screen

Intuitive authentication status display via a 2.8″ color LCD

Widescreen image

02
User-Friendly Design

Easily check the scanning position with QR codes at the top and bottom and a 3000K white LED

User-Friendly UI Image

03
Physical Keypad

You can enter a password and change modes using the touch keypad

Clear Image of the Reading Light

04
Low-Power QR Module

Provides an efficient operating environment through low-power QR module design

Image of a Low-Power QR Module

Versatility

The UBio-X QScan can be used in a variety of settings, including construction sites, warehouses, prisons, and military bases.

AC5000Plus IK 10

Construction Site

AC5000Plus IK 12

Military Unit

warehouse workers checking inventory on storage sh 2026 09 25 01 20 24 utc 1

Warehouse

houston texas usa cityscape 2026 09 24 08 39 58 utc 1

Commercial Facilities

Specifications

스크롤을 좌/우로 움직이세요

* Use horizontal scrolling.

Model		UBio-X QScan
Authentication Method		QR Code/Card/PIN
User Capacity	Card/QR 1:N	20,000
User Capacity	Logs	64,000
Hardware	CPU	ARM Cortex-A5, 536 MHz
	RAM & ROM	32 MB NOR Flash / 128 MB NAND Flash / 128 DDR
	Display	2.8″ Color LCD
	Interface	TCP/IP, Wiegand In/Out, RS485, RS232
	Relay / Monitor	2 Locks, 4 Monitors
	Dimensions (W) x (H) x (D) mm	88 x 175 x 43.5
Card	RF Option	Felica 13.56 MHz ISO 14443 A/B Option: HID EM/iClass
Power	Adapter	24V (Japan)
Operating Temperature		-20 to 55°C
QR Specification	QR Code (15 mil)	20 mm to 60 mm
	Data Matrix (10 mil)	20 mm to 45 mm
	PDF417 (6.7 mil)	20 mm to 45 mm
	Code 39 (5 mil)	20 mm to 60 mm
